What is a high-pressure oil pipe?
High pressure oil pipes are a component of the high-pressure oil circuit, which requires the oil pipes to withstand a certain amount of oil pressure and have a certain fatigue strength to ensure the sealing requirements of the pipelines. High pressure oil pipes for vehicles mainly appear in high-pressure injection diesel engines and high-pressure injection direct injection gasoline engines, and can withstand the oil pressure required during engine operation.
Classification of high-pressure oil pipes: high-pressure steel wire woven hose, high-pressure steel wire wrapped hose, large-diameter high-pressure hose, steel wire (fiber) reinforced nylon elastomer resin pipe, steel wire reinforced soft, ultra-high pressure hose, high-temperature resistant hose, polyurethane hose.
High pressure oil pipe usage: used for excavators, loaders, side dump trucks, hydraulic assistance, hydraulic supports, cement conveying pipes, agricultural irrigation hoses, hydraulic oil pipes for engineering machinery, subsea natural gas transportation, and oil transportation.
The oil pipe is composed of a steel wire wrapped skeleton layer and an oil and corrosion resistant synthetic rubber inside and outside. Longkou Tongda Oil Pipe Co., Ltd. is a modern enterprise that produces various diesel engine, gasoline engine oil pipes, water pipes, air pipes, PTFE oil pipes, automotive silencing pipes, ternary catalytic gas, and modified series products. It is a supporting equipment for more than ten domestic automotive engineering machinery and diesel engine factories, and its products are exported in batches to countries in Europe, America, and Southeast Asia.
High pressure oil pipe usage
The oil pipe is composed of a steel wire wrapped skeleton layer and an internal and external oil and corrosion resistant synthetic rubber, which is used for the transportation of medium such as hydraulic oil pipes for engineering machinery, subsea natural gas, petroleum, irrigation, steel mills, chemical plants, etc.
Classification: high-pressure steel wire woven hose, high-pressure steel wire wrapped hose, large-diameter high-pressure hose, steel wire (fiber) reinforced nylon elastomer resin pipe, steel wire reinforced soft, ultra-high pressure hose, high-temperature resistant hose, polyurethane hose.
Structure: The high-pressure oil pipe is composed of a steel wire wrapped skeleton layer, internal and external oil resistant rubber, corrosion-resistant synthetic rubber, and weathering resistant special rubber.
Usage: Used for excavators, loaders, side dump trucks, hydraulic assistance, hydraulic supports, cement conveying pipes, agricultural irrigation hoses, hydraulic oil pipes for engineering machinery, subsea natural gas transportation, and oil transportation.
Manufacturing process of high-pressure oil pipes
1. Mix the inner layer adhesive, middle layer adhesive, and outer layer adhesive according to the formula using a mixer; Extrude the inner oil pipe with an extruder and wrap it on a soft or hard core coated with a release agent (the liquid nitrogen freezing method also does not require a pipe core)
2. The calender presses the middle layer of adhesive into thin sheets, adds blocking agents to roll them up, and cuts them into regular widths according to the process requirements
3. Wrap the inner layer oil pipe containing the pipe core around a copper plated steel wire or copper plated steel wire rope on a wrapping machine or weaving machine, and synchronously wrap the middle layer adhesive sheet between each two layers of copper plated steel wire or copper plated steel wire rope on the wrapping machine or weaving machine. Bind the beginning and end of the wrapping steel wire (some early wrapping machines require pre stressing and shaping of the copper plated steel wire)
4. Wrap the outer layer of adhesive on the extruder again, and then wrap it with a lead or cloth vulcanization protective layer
5. Through vulcanization tank or salt bath vulcanization
6. Finally, remove the vulcanization protection layer, extract the pipe core, buckle the upper pipe joint, and conduct sampling, compaction, and inspection.
Seven major usage requirements for high-pressure oil pipes
Each product has its own application requirements, and high-pressure oil pipes are no exception. Today, Changhao High Pressure Oil Pipe Factory will analyze the seven main application requirements for high-pressure oil pipes for you:
1. The internal working pressure (including pulse pressure) of high-pressure oil pipes shall not exceed the maximum working pressure specified in the hose planning rules.
2. It shall not be used in a state that exceeds the working environment requirements of high-pressure oil pipes.
3. High pressure oil pipes are only suitable for planning the transportation of media.
4. The application device shall not be less than the planned bending radius of the high-pressure oil pipe.
5. High pressure oil pipes should not be used in a distorted state.
6. It is necessary to meet the requirements for the amount of high-pressure oil pipe compression, and the joint size and accuracy should meet the regulatory requirements.
7. High pressure oil pipes are vulnerable parts and should be inspected and replaced regularly.
Post time: Sep-08-2023
